Brand: Aircon

Product Name: AIRCON FLOOR & CEILING MINI SPLIT HEAT PUMP 16 SEER 24,000 BTU

Item#:	ASKCI4H4R24 ASKEL4H4R24
Reg Price:	$3,486.99
Your Price:	$2,418.89
Accessories:	Whats This? 25 ft of Copper Line Set with insulation for just $99 only! (worth $165 in retail stores) $149.99 Opt Out
Total Price :	$2,568.88
Choose QTY:	Required

Product Details - ASKCI4H4R24 ASKEL4H4R24

Model	Unit	ASKCI4H4R24 ASKEL4H4R24
Power Supply	V/Ph/Hz	208/230/1/60
Cooling Capacity (Min~Max)	Btu/h	23,884(8,188- 29,002)
Heating Capacity (Min~Max)	Btu/h	27,296(8,188- 32,414)
Cooling Power Input (Min~Max)	KW	2.25(0.85-2.50)
Heating Power Input (Min~Max	KW	2.28(0.80-2.75)
Cooling Current Input (Min~Max)	A	10.1(3.60-11.00)
Heating Current Input (Min~Max)	A	10.2(3.40-12.00)
Air Flow Volume	m3 /h	1200
Air Flow Volume	CFM	706
Dehumidification Volume	Pint/h	0.99
Dehumidification Volume	L/h	0.36
EER	(Btu/h)/W	10.7
SEER		16
INDOOR UNIT
Sound Pressure Level (SH/H/M/L)	dB(A)	49/48/46/40
Dimension (W/D/H)	inch	48/27.6/8.9
Dimension (W/D/H)	mm	1219/701/226
Net Weight	lb	88.2
Net Weight	Kg	40
Gross Weight	lb	110.3
Gross Weight	Kg	50
Cable Gauge	AWG	16AWG
OUTDOOR UNIT
Sound Pressure Level (SH/H/M/L)	dB(A)	57
Dimension (W/D/H)	inch	38.6/16.8/31.1
Dimension (W/D/H)	mm	980/426/790
Net Weight	lb	147.7
Net Weight	Kg	67
Gross Weight	lb	158.8
Gross Weight	Kg	72
Cable Gauge	AWG	16AWG
Refrigerant		R410A
Refrigerant Charge	Oz	77.6
Refrigerant Charge	G	2200
Breaker Capacity	A	2-Pole 20A
Cable Gauge	AWG	13AWG
PIPE Connections
Testing Pipe Length/Additional Charge Over	ft	16.4/23.0
Testing Pipe Length/Additional Charge Over	m	5/7
Connection Pipe Gas Additional Charge	oz/ft	0.6
Connection Pipe Gas Additional Charge	g/m	55.8
Outer Diameter Liquid Pipe	inch	3/8
Outer Diameter Liquid Pipe	mm	9.525
Outer Diameter Gas Pipe	inch	5/8
Outer Diameter Gas Pipe	mm	15.9
Max Distance Height	ft	49.2
Max Distance Height	m	15
Max Distance Length	ft	98.4
Max Distance Length	m	30
AHRI Certification		7826817
